Model: FTV – 2F – EVS
Year: New
Type: Knee Mill
SPECIFICATIONS:
Table Size……………. 10” x 55-1/4”
Longitudinal Travel..(X).. 38-1/2”
Cross Travel………(Y).. 16”
Vertical Travel……(Z).. 16”
Quill Travel………….. 5”
Dist. Spindle to Table…. 18”
Spindle Taper…………. #40
Spindle Speeds (VS)……. 0 – 4000 RPM
Motor Size – Voltage…… 5 HP – 220/440V – 3 Phs
Table Weight Capacity….. 550 Lbs
Weight……………….. 2850 Lbs
Dimensions……………. To Be Advised
EQUIPPED WITH:
STANDARD EQUIPMENT:
Electronic Variable Speed
Flood Coolant System
One Shot Lube
Draw Bar
Operation Manual
MACHINE FEATURES:
Meehanite Castings
Precision Hard Chrome Quill
H & Precision Ground Ways
Class 7 Spindle Bearings
Turcite Coating On X – Y Axis
OPTIONAL ACCESSORIES AVAILABLE: P.O.R.
Halogen Work Light
(7) Pcs. #40 Collet Set
6” Kurt Type Vise
6” Kurt Precision Vise
Automatic Draw Bar
Table Power Feed (X)
Table Power Feed (Y)
Table Power Feed (Z)
Power
COMMENTS:
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need a Part ?
Have a Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
