Model: 3-VK-MR
Type: CNC Knee Mill … Rigid Head … Moveable Ram
Year: New
SPECIFICATIONS:
Table Size:…………… 10” x 54”
Table Travel………(X).. 31”
Table Travel………(Y).. 14
Quill Travel………(Z).. 4-1/2”
Knee Travel…………… 16″
Spindle Nose-Table Top:… 3/4” to 16-3/4”
Motor Size:…………… 3 HP – 220V – 3 Phs
Spindle Speeds(VS)…….. 70 – 5000 RPM
Spindle Taper:………… R-8
Table Load Cap.:………. 600 Lbs
Rapid Traverse:……….. 150 IPM
Weight:………………. 3100 Lbs
Control Type:…………. Centroid M-400S
Dimensions (LxWxH)…….. 108″ x 77″ x 92″
STANDARD EQUIPMENT:
Centroid M-400-S CNC Control
“Conversational” (Shop Floor Programming)
“G-Code”
15” Color Monitor
RS-232 & Ethernet Ports
(1) GB Solid State Hard Drive
Hard Limit Switches
Draw Bar (Manual)
Automatic Lubrication
Coolant System
Table Guard (Optional)
Work Light
Way Covers
Tool Box w/Tools
Leveling Bolts
MACHINE FEATURES:
(3) Axis
Variable Speed – (Programmable)
H & G w/Turcite Covered … Box Ways
“Back Gear” For Heavy Cutting
Meehanite Casting
Precision Ball Screws
29 In/LB Motor
Handles (X,Y, & Knee)
Box Ways (Y Axis)
OPTIONAL ACCESSORIES:
Power Draw Bar
Mist Coolant
440V Transformer
Upgrade From 3 HP to 5 HP
6” IMCO (Kurt Type) Vise
6” Kurt Precision Vise
(52) pc Clamping Kit
Table Guard
“Z” Axis Scale Feed Back for 3rd Axis Quill
6” Riser Block
8” Riser Block
(11) R-8 Collets
SOFTWARE OPTIONS (CENTROID CONTROL)
Multiple Work Coordinate System
User Definable Macros & Sub Programs – Standard
Compression Tapping – Standard
Scaling & Mirroring
Unlimited Part Program Size
4th Axis Software – Standard
Coordinate System Rotation
DXF In, CAD Drawing Input Software
Cutter Compensation – Standard
Intercon Off-Line Conversational Program (For Desktop PC)
Engraving Software
DIGITIZING & PROBING
2D & 3D Digitizing Software (Includes Mold Majic Software)
DP-4 Probing Package
TT-1 Tool Touch Off Kit
Toolroom Package:
DP-4-Probing Package
TT-1 Tool Touch Off Kit
Work Coordinate System
ACCESSORY
(100) Step Mps Hand Wheel
Installation & Set-Up **
Control Training **
**Plus Travel Expense
COMMENTS:
Control Mfg. In U.S.A.
