Model: 1054
Type: CNC Bed Mill
Year: New
SPECIFICATIONS:
Table Size……………… 10” x 54”
Table Travel………..(X).. 31.5”
Table Travel………..(Y).. 20”
Head/Knee Travel…….(Z).. 20.87”
Spindle Nose To Table Top… 25.39”
Motor Size……………… 5 HP – 220V-1 Or 3 Phs
Spindle Speeds………….. 50 – 3750 RPM
Spindle Taper…………… Cat 40
Table Load Capacity……… 1320 Lbs
Rapid Traverse………….. 200 IPM
Weight…………………. 4760 Lbs
Dimensions……………… To be Advised
Control Type……………. Accu-Rite Millpower G2 CNC
EQUIPPED WITH:
ACCU-RITE MILLPOWER G2 CNC CONTROL
ABS/Inc – Inch/Metric
Polar/Cartesian
Rectangle (Pocket, Frame, Slot & Face)
Circle (Pocket, Frame & Ring)
Interactive ICON Based Conversational
10” Color LCD Flat Panel Display
DXF Converter for G-Code
Engraving: (3) Font Types
Hole Patterns (Bolt Circle, Array, Frame & Row)
Repeat, Rotate, Mirror Image & Engraving
Position/Drill
Lines, Diagonals & Arcs
Blends (Corner Radius)
User Friendly (Fill in the Blanks & Start)
(3) 29 in/lb DC Brush Servo Motors
Built-in 512 MB CF w/999 Block Capacity
Numberous Canned Cycles in Conversational
MACHINE FEATURES
(3) Axis
Meehanite Casting
H & G Table
Turcite-B Coated Slideway & Gibs
Class 7 Precision Spindle Bearings
OPTIONAL ACCESSORIES:
Edge Finder Probe (.5” Shank, .2” Probe)
“Z” Axis Digital Readout
Power Draw Bar & Safety Ring – Installed
12“ Rotary Table (Vertical & Horizontal)
T-Slot Cover
(52) pc Clamp Kit
6” Precision Vise
Coolant System – Installed
Chip Pan& Rear Splash Guard
Halogen Work Light
Upgrade to 440V – 3 Phs Motor
Set-Up/Control Training…. (Per Day)… $ 950*
*Plus Travel Expense
COMMENTS:
USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need a Part ?
Have a Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B. Location
TERMS: Check w/Order
All prices subject to change without notice
