Model: BM-430-H
Type: CNC Bed Mill
Year: New
SPECIFICATIONS:
Table Size……………… 13.7” X 50”
Table Travel………..(X).. 31.5”
Table Travel………..(Y).. 15.7”
Head Travel…………(Z).. 17.7”
Spindle Nose To Table Top… 22.4”
Motor Size……………… 7.5 HP – 230V – 3 Phs
Spindle Speeds(V.S.)…….. 60 – 8000 RPM
Spindle Taper…………… Cat 40
Table Load Capacity……… 880 Lbs
Rapid Traverse………….. 250 IPM
Weight…………………. 5500 Lbs
Dimensions……………… To be Advised
Control Type……………. Centroid M-400
EQUIPPED WITH:
STANDARD EQUIPMENT
(3) Axis Centroid M-400 Control
Conversational (Shop Floor Programming)
“G” Code
15” Color Monitor
RS-232 & Ethernet Ports
(1) GB Solid State Hard Drive
Auto Lube
Coolant System
Halogen Work Light
Splash Guard
Leveling Bolts & Pads
Tool Box w/Tools
MACHINE FEATURES
(3) Axis
Spindle Speeds (Programmable
H & G Box Ways (Y & Z Axis)
(4) Box ways
Bed Ways – Turcite Coating
Meehanite Casting
“Double Nut” – Precision Ball Screws
(1) Year “Machine Parts” Warranty
(1) Year “Control” Warranty
OPTIONAL ACCESSORIES AVAILABLE:
OPTIONAL ACCESSORIES: (“CNC” MILL)
6” IMCO (Kurt Type) Vise
6” Precision Kurt Vise
(6) End Mill Adaptors (3/16” – 1”)
5.9” Rotary Table Package (Includes 4th Axis Pre-Wire)
7.8” Rotary Table Package (Includes 4th Axis Pre-Wire)
(52) PC. Clamping Kit
Table Guard
10” Riser Block (Engine Block Job Shop)
17 KVA Transformer (440/480V)
(16) Station Automatic Tool Changer Magazine w/Software
(20) Station Automatic Tool Cchanger Magazine w/Software
Mist Coolant System
Table Guard
Full Enclosure
SOFTWARE OPTIONS (CENTROID CONTROL)
Drilling Cycles – Standard
Rigid Tapping
Multiple Work Coordinate System
User Definable Macros & Sub Programs – Standard
Compression Tapping – Standard
Scaling & Mirroring
Unlimited Part Program Size
4th Axis Software – Standard
Coordinate System Rotation
DXF In, CAD Drawing Input Software
Cutter Compensation – Standard
Intercon Off-Line Conversational Program (For Desktop PC)
Engraving Software
DIGITIZING & PROBING
2D & 3D Digitizing Software (Includes Mold Magic Software)
DP-4 Probing Package
TT-1 Tool Touch Off Kit
Toolroom Package:
D4 Probing Package
TT-1 Tool Touch Off Kit
Work Coordinate System
ACCESSORY
(100) Step MPG
Installation & Set-Up… Per Day
Control Training … Per Day
Plus Travel Expenses
CONDITION: Very Good
PARTS & SERVICE
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
