Model: “G”
Type: Geared Head
Year: New
SPECIFICATIONS:
Swing Over Bed………… 14”
Swing Over Cross Slide…. 9”
Swing In Gap………….. 21”
Dist. Between Centers….. 40”
Spindle Nose………….. D1-4
Spindle Hole………….. 1-9/16”
Bed Width…………….. 10”
Spindle Speeds(8)……… 85 – 2000 RPM
Threading…………….. Inch/Metric
Motor Size……………. 3 HP – 220/440V – 3 Phs
Tailstock Taper……….. #3 MT
Weight……………….. 2550 Lbs
Dimensions……………. 78″(l) x 30″(w) x 60″(h)
EQUIPPED WITH:
6″ – 3 Jaw Chuck
8″ – 4 Jaw Chuck
(4) Way Toolpost
Coolant System
Full Length Splash Guard
Chip Tray
(0.4″ – 4.3″) Steady Rest
12″ Face Plate
Halogen Work Light
Tools w/Tool Box
Operation Manuals
MACHINE FEATURES:
Mfg. in Tawain
1-9/16″ Spindle Hole
Hardened & Ground Headstock Gears
Hardened & Ground Bed Ways
Main Spindle Equipped w/(2) Precision Bearings
Tailstock Barrel (Inch-Metric)
Control Switch (Electro-Magnetic)
Foot Brake
Jog Button … Emergency Stop Button
“OPTIONAL ACCESSORIES” AVAILABLE … P.O.R.
8″ – 3 Jaw “Set Tru ” Chuck
8″ – 6 Jaw “Set Tru” Chuck
Micro Carriage Stop
(4) Position Carriage Stop
Taper Turning Attachment
Lever Collet Attachment
5C Collet Set (1/8″ – 1-1/8″ x 1/16″)
“Aloris Type ” Quick Change Toolpost w/(6) Holders
14N Jacobs “Ball Bearing” Chuck w/Arbor (0″- 1/2″Capacity)
#3 MT Live Center
Upgrade to 440V – 3 Phs – Inverter Drive
Newall Digital Readout
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need a Part ?
Have a Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
