Model: KC-25120
Type: Geared Head Lathe
Year: New
SPECIFICATIONS:
Headstock Type……….. Geared Head
Swing Over Bed……….. 24.8”
Swing Over Cross Slide… 17.71”
Swing in Gap…………. 31.88”
Dist. Between Centers…. 120”
Spindle Nose…………. D1-8
Spindle Hole…………. 3.34” (4.13” & 6.1” Opt)
Bed Width……………. 13.7”
Spindle Speeds……….. (VS) 25 – 1550 RPM
Threading……………. Inch/Metric
Motor Size…………… 15 HP – 220/440V – 3 Phs
Tailstock Taper………. #5 MT
Weight………………. 9340 Lbs
Dimensions…………… To be Advised
EQUIPPED WITH:
(4) Way Toolpost
Coolant System
One Shot Lube
Full Length Splash Guard
(1) Back Plate for 3-Jaw Chuck
Thread Dial
Center & Center Sleeve
Foot Brake
Leveling Block
Halogen Work Light
Tool Kit
Manuals
MACHINE FEATURES:
3.34″ Spindle Hole
Gap Bed Design
Overload Clutch
H & G Headstock Gears
H & G Bedways
(1) Piece Cast Meehanite Bed
OPTIONAL ACCESSORIES:
10″ – 3 Jaw Chuck
12″ – 3 Jaw Chuck
Upgrade 4.13” Spindle Bore w/D-11 Nose (Speeds: 23 – 1300 RPM)
Upgrade 6.1” Spindle Bore w/A2-11 Nose (18 Speeds)
(2.3” – 11”) Steady Rest
(16”) Face Plate
Follow Rest
Micro Meter Carriage Stop
Taper Attachment
Newall Digital Readout – Installed
COMMENTS:
“U.S.A.” IMPORTER – DISTRIBUTION & PARTS CENTER
Need a Part ?
Have a Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
