Model: F-2024-HA-CNC
Year: New
Type: Double Column / Fully Automatic
SPECIFICATIONS
Cutting Capacity
Rounds:
At 90 Degrees… 20”
Rectangle
At 90 Degrees… 20” x 24”
Work Height……….. 35”
Blade Size………… 1-1/2” x .050” x 20’
Blade Speed(V.S.)….. 60-500 SFPM
Motor Size………… 10 HP-230/460V-3 Phs
Weight……………. 5500 Lbs
EQUIPPED WITH:
Fully Automatic CNC Bar Feed
Bar Feed Projection (CNC Controlled) 0-25”
Color Touch Screen Controls
500 + Job Selection
Automatic Kerf Compensation
Part Length Up To 99,999”
On-Screen Help Menu
AC Vector Drive
Digital Blade Speed Indicator
Variable Vise Pressure
Hydraulic Blade Tension
Saw Bed & Vise Wear Strips
NFPA 79 Electrics, NFPA Interlocks
Electronic Door Safety Interlocks
Blade Break/Stall Switch
Machine Diagnostics
Built-In Fork Lift Pockets
OPTIONAL ACCESSORIES AVAILABLE … P.O.R.
Air Hold Down (Saw & Bar Feed Vises)
Electronic Chip Conveyor (Auger Style)
20”W x 48”L Discharge Work Table
Work Light
Extra Coolant Nozzle w/Magnetic Base
High Speed (1” Blade) 400 – 3,000 SFPM
6” Centers – Free Standing Roller Stock Conveyor
24” x 5; x 5000 LBS Capacity
24” x 10’ x 10,000 LBS Capacity
COMMENTS: Mfg. In U.S.A.
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need A Part !
Have A Technical Question !
CALL: IMCO At 614-914-5087
F.O.B.: Columbus, Ohio
TERMS: Check w/Order
All prices subject to change without notice
