Model: ARS-2.2 … PK-35
Type: Single Pinch
Year: New
SPECIFICATIONS:
Shaft Diameter:……. 1.97″
Roll Diameter:…….. 6.1″
Driven Rolls:……… 2 (Lower)
Rolling Speed:…….. 2 (7.5 & 15 FPM)
Work Plane:……….. Horizontal / Vertical
Adjustable Rolls:….. 1
Motor:……………. 1-1/2″ + 2 HP – 220/440V – 3 Phs
Weight:…………… 880 Lbs
CAPACITIES:
Flats Hard……… 2-3/8″ x 3/8″ x 20″ Dia
Flats Easy……… 4″ x 9/16″ x 18″ Dia
Square Bar……… 1-3/8″ x 36″ Dia
Angle Leg Out…… 2″ x 2″ x 1/4″ x 32″ Dia
Angle Leg In……. 2″ x 2″ x 1/4″ x 40″ Dia
Tee Leg Out…….. 2-3/8″ x 1/4″ x 28″ Dia
Tee Leg In……… 2-3/8″ x 1/4″ x 28″ Dia
Channel Leg Out…. 3-1/8″ x 40″ Dia
Channel leg In….. 3-1/8″ x 48″ Dia
Round Bar………. 1-3/8″ x 24″ Dia
Pipe…………… 2″ Sch. 40 x 40″
Tubing Square…… 2″ x 2″ x 11 Ga x 67″
Tubing Rectangle… 2-3/4″ x 1-3/16″ x 14 Ga x 48″
EQUIPPED WITH :
(3) Rolls
Single Pinch
H & G Shafts & Gears
Mechanical Drive
(2) Powered Rolls
Hydraulic Adjustable Top Roll w/Pressure Gauge
(1) Set of Universal Tooling
Emergency Stop Button
Movable Control Console
OPTIONAL ACCESSORIES AVAILABLE: P.R.O.
Variable Speed – 1 Phs
