Model: 2018
Year: NEW
SPECIFICATIONS:
Throat……………… 18” @45 Degrees – 13-1/4″
Table Size………….. 28” x 29”
Clearance Under Guide… 20”
Cutting Capacity:
At 45 Degrees…… 13-1/4″
Work Height…………. 34-3/4″”
Blade Size………….. 14′-6” x 1” x .035”
Blade Speed…………. 99-275 SFM
Motor Size………….. 2 HP – 230/460V – 3 Phs
Weight……………… 1350 Lbs
EQUIPPED WITH:
Coolant Pump & Hose
Coolant Tray
Quick Acting Vise
Work Light
MACHINE FEATURES:
Head Tilts 45 Degrees Left & Right & 3 Degrees Forward to Optimize Feed Rate
Infinite Adjustable Feed Force
Feed Mechanism Controlled Air Hydraulic Cylinder
Manual Hand Crank for Feed
Variable Blade Speed
Head Mounted Drive
Steel Drive Wheels
Counterbalanced Head for Easy (1) Person Operation
Controls Located Above Work on Frame
Carbide Blade Guides
No “Stooping Over” when Cutting Materials
Precision Machined Steel Table Top can be Resurfaced or Replaced
Chrome Hardened Ways Support Carriage
“Quick-Acting” Vise Clamps from Either Side of Vise
COMMENTS: MFG. In The U.S.A.
