Model: OL-1220 … Centroid T-400i CNC Control
Spindle Hole: 1-9/16″
Type: Flat Bed
Year: New
SPECIFICATIONS:
Swing Over Bed:……….. 12.6”
Swing Over Cross Slide:… 7”
Dist Between Centers:….. 20”
Max. Turning Length:…… 19-1/2”
Spindle Nose:…………. D1-4
Spindle Hole:…………. 1-9/16”
Bed Width:……………. 7-9/16”
Spindle Speeds:……….. 25 – 4000 RPM
Spindle Ranges:(3)…….. Automatic Shift
Tailstock Taper:………. #3 MT
Rapid Traverse:……….. 360 IPM
Motor Size:…………… 5 HP – 220V – 3 Phs
Control Type:…………. Centroid T-400i CNC Control
Weight:………………. 1720 Lbs
Dimensions……………. 70″(l) x 48″(w) x 60″(h)
STANDARD EQUIPMENT
Centroid T-400i CNC Control
“Conversational” (Shop Floor Programming)
“G” Code
15” Color Monitor
RS-232 & Ethernet Ports
(1) GB Solid State Hard Drive
Totally Enclosed (Sliding Door)
Safety Chuck Guard
Auto Lube System
Quick Change Tool Post
Coolant System
Back Plate
Work Light
Tool Box w/Tools
Leveling Bolts
Operations Manual
MACHINE FEATURES:
1-9/16” Spindle Hole
Flat Bed Design … H & G Ways
“Dual” Electronic Hand Wheels For Manual Operation,
“Laser” Tested Accuracy
T-Slotted Rear Cross Slide
Meehanite Casting
H & G Precision Ballscrews & Bed Ways
Tailstock Manual
OPTIONAL ACCESSORIES AVAILABLE:
6” – 3 Jaw Chuck
8” – 3 Jaw Chuck
Lever Collet Attachment 1-1/16” (5C) … Manual
Lever Collet Attachment 1-1/16″ (5C) … Pneumatic … 1/16” – 1-1/16” Capacity
Rigid Tapping
Installation & Set-Up….(Per Day)… Plus Travel Expenses
Control Training….(Per Day)… Plus Travel Expenses
COMMENTS: Control Mfg. In USA
