Model: JF-4VS
Type: Knee Mill
Year: New
SPECIFICATIONS:
Table Size……………. 10” x 54”
Longitudinal Travel..(X).. 40”
Cross Travel………(Y).. 16”
Vertical Travel……(Z).. 16”
Quill Travel Dist……… 5”
Spindle To Table………. —
Spindle Taper…………. R-8
Spindle Speeds..(VS)…… 60 – 4200 RPM
Motor Size – Voltage…… 3 HP – 220/440V – 3 Phs
Table Weight Capacity….. 750 Lbs
Weight……………….. 3450 Lbs
Dimensions……………. To Be Advised
EQUIPPED WITH:
Draw Bar
Front & Rear Rubber Way Covers
One Shot Lube System
Operation Manual
Tool Box w/Tools
MACHINE FEATURES:
Meehanite Casting
H & G on X & Y Slideway
H & G Table
Turcite Coating on X & Y Axis Slideway
Square Way on Y & Z Axis Slideway
Double Saddle Locks
High Precision Chromed Quill
“Back” Gear for Heavy Cutting
(4) Way Tilt Head
NOTE: Head Tilts … 90 Deg. L & R / 45 Deg. F & B
COMMENTS:
“USA” Importer – Distribution & Parts Center
Need a Part?
Have a Technical Question?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
