Model: Jaws IV … (4) Work Stations
Punch Capacity: 1-1/16″ Hole Thru 5/8″ Plate
Type: Hydraulic
Year: New
SPECIFICATIONS:
PUNCHING:
Max Tonnage…………. 55 Ton
Punch Capacity………. 1-1/16″ Hole Thru 5/8″ Plate
1″ Hole Thru 11/16″ Plate
Max. Stroke Length…… 1-1/4″
Throat……………… 7-1/2″
SHEARING:
Flat Bar (14″ Blade)…. 14″ x 3/8″
4″ x 3/4″
Angle Shear @ 90 Degree. 3″ x 3″ x 3/8″
4″ x 4″ x 1/4″
Round Bar…………… Up to 7/8″ (Optional)
Square Bar………….. Up to 7/8″ (Optional)
Coper Notcher……….. 2″ x 3″ x 5/16″ (Optional)
Vee Notcher…………. 3″ x 3″ x 1/4″ (Optional)
Motor Size………….. 5 HP – 220V – 3 Phs
Weight……………… 2480 Lbs
Dimensions………….. 44-3/8″(l) x 36-1/8″(w) x 55-1/4″(h)
EQUIPPED WITH:
(4) Separate Work Stations:
Punching Station
Flat Bar Shear
Angle Share
Open Tooling Station
Keyed Punch Ram
Punch Holder, Adapter & Stripper
Movable Foot Pedal
Electric Stroke Control
Pedestal Die Table
Safety Guards
OPTIONAL ACCESSORIES:
440V – 3 Phs
220V – 1 Phs
Please Contact us for Complete List of Optional Accessories
COMMENTS: Mfg. in U.S.A.
