Model: M-7475-B
Chuck Diameter: 30″
Year: New
SPECIFICATIONS:
Chuck Diameter:…. 30”
Chuck Life:…….. 100%
Vertical Travel:… 17.7”
Wheel Size:…….. 18” x 15” x 6”
Grinding Wheel:…. 1200 RPM … (5700 SFM)
Magnetic Chuck:…. (2)Speeds … 16 – 24 RPM
Motor Size:…….. 35 HP – 220V – 3 PHS
Weight:………… 12,130 LBS
EQUIPPED WITH:
(2) SPEED CHUCK … 16 – 24 RPM
CYLINDER GRINDING WHEEL
WHEEL DRESSER
BALANCING ARBOR
COOLANT SYSTEM
WORK LIGHT
SOLID WHEEL ADAPTER
LEVELING WEDGES
INSTALLATION
TRAINING
SERVICE SPARE PARTS
(1) YEAR PARTS & LABOR
COMMENTS:
Catalog Photo
Current … 100 Amps
A) “U.S.A.” IMPORTER – DISTRIBUTION & PARTS CENTER
Need A Part ?
Have A Technical Question ?
Call: IMCO at 614-914-5087
F.O.B.: Columbus, Ohio
Terms: Check w/Order
All prices subject to change without notice
