Model: TL-618-EVS
Type: Tool Room
Year: New
SPECIFICATIONS:
Headstock…………….. Geared Head
Swing Over Bed:……….. 11”
Swing Over Cross Slide:… 6”
Swing In Gap:…………. No Gap
Dist. Between Centers:…. 18”
Spindle Nose:…………. 5C Collet
Spindle Hole:…………. 1-1/16”
Bed Width:……………. To Be Advised
Spindle Speeds:(VS)……. 130 – 4000 RPM
Threading:……………. Inch / Metric
Motor Size:…………… 5 HP – 220V – 1 or 3 Phs
Tailstock Taper:………. #2 MT
Weight:………………. 2530 Lbs
Dimensions……………. To be Advised
EQUIPPED WITH :
Digital Variable Speed Drive
5C Collet Closer
(2) 5C Collets
Splash Guard
Lead Screw Cover
Coolant System
Work Light
Tail Stock
Spindle Nose Cover
Chuck Guard
Floor Stand
“OPTIONAL ACCESSORIES” AVAILABLE … P.O.R.:
6” – 3 Jaw Chuck
6” – 4 Jaw Chuck
6” – 6 Jaw Chuck
5C Collet Set (1/8” to 1-1/16” x 1/16”)
Aloris Quick Change Toolpost w/(7) Holders
Vertical Cut Off Slide
Taper Attachment (Installed)
Steady Rest
Follow Rest
(2) Axis Newall Digital Readout (Installed)
