Model: RKL-2900GH
Type: Geared Head
Year: New
SPECIFICATIONS:
Headstock……………. Geared Head
Swing Over Bed……….. 30”
Swing Over Cross Slide… 21.6”
Swing in Gap…………. 39”
Dist Between Centers….. 117”
Spindle Nose…………. D1-11
Spindle Hole…………. 4.1”
Bed Width……………. 16”
Spindle Speeds (12)…… 13 – 1200 RPM
Threading……………. Inch/Metric
Motor Size…………… 15 HP – 480V – 3 Phs
Tailstock Taper………. #5 MT
Gross Weight…………. 7900 Lbs
Dimensions…………… 177″(l) x 72″(w)
EQUIPPED WITH:
(4) Way Toolpost
Steady Rest w/Roller Jaws
Follow Rest w/Bronze Jaws
Face Plate
Telescopic Taper Attachment
Full Length Splash Guard
Chuck Guard
Coolant System
Chip Pan
Brake Pedal
Halogen Work Light
Leveling Pads
Tool Box w/Tools
Operation & Parts Manual
MACHINE FEATURES
4.1″ Spindle Hole
H & G Gears & Bed Ways
Gap Bed
Spindle Supported by (3) Tapered Roller Bearings
Meehanite Casting Bed
Precision Ground Bed
OPTIONAL ACCESSORIES:
10″ – 3 Jaw Bison Chuck
12″ – 3 Jaw Bison Chuck
12″ – 4 Jaw “Steel” Bison Chuck
Taper Turning Attachment
Lever Collet Attachment
5C Collet Set (1/8″ – 1-1/8″ x 1/16″)
“Aloris Type” Quick Change Toolpost w/(5) Holders
14N Jacobs “Ball Bearing” Chuck w/Arbor (0″ – 1/2″ Capacity)
#4 MT Live Center
Newall Digital Readout
COMMENTS:
Need a Part?
Have a Techicnial Question?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
